3D CO ORDINATE MEASURING MACHINE
- Model : LH12103D
- Make : Wenzel Germany
- Operation : CNC Measuring Range :
- X axis : 1200mm
- Y axis : 2500mm
- Max.Workpiece weight (kg) : 3000Kgs
- Clearance under bridge (mm) : 1590mm
V7-1100 TRIMOS HEIGHT GAUGE
- Make : Swiss
- 2D Model : Vertical Measuring Instrument
- Measuring Range : 1110 mm
- Measuring Range with Extension : 1422 mm
- Manual or Motorized Displacement Mode : MA/MO with air cushion
DNM-LYNX 220 - TURNING CENTER
- MAKE: Korea
- DIAMETER: 320 mm
- LENGTH: 520 mm
- SPEED: 4,000
- TOOLS - ATC: 12 nos
CMM - CARL ZEISS
- MAKE: Germany
- TRAVELS (X,Y,Z): 700x1000x600 mm
ZOLLER SMILE / PILOT 1.0
- MAKE: Germany
- MAX TOOL LENGTH Z: 600 mm
- MAX TOOL LENGTH D: 420 mm
- OPERATION: 100 mm (snap gauge)
CONTOUR MEASURING MACHINE
- MAKE: Germany
- MODEL: Contourecord 1600G - 12N
2D HEIGHT MASTER
- MODEL: M'height 625
- MAKE: Microtechinka
- REPEATABLITY: 2(Plane) 3(Dia) microns
- MEASURING RANGE: 825 mm
